Audio Panel Features
|
| Telephone interface |
dedicated full-duplex tel interface (no PTT keying required) |
| ICS (intercom system) |
6 to 7 position intercom (individual VOX processing for each of the mic positions) |
| ICS isolation modes |
8 - synoptic graphical selection |
| Transceivers |
3 - COM1, COM2, COM3 |
| Additional receiver inputs |
5 - NAV1, NAV2, (RCVR3), (RCVR4), (RCVR5) |
| Music source input |
2 Stereo music source inputs |
| Music input impedance |
600 Ohms |
| Music frequency response |
20Hz - 20kHz |
| Speaker output |
28V aircraft — 10W into 4 Ohms, 7W into 8 Ohms; 14V aircraft — 3W into 4 Ohms |
